MiniHawk - Hybrid Anamorphics

full blown anamorphic look | super close focus | high speed optics | ultra compact | spherical delivery | well-suited for CG

Compact, lightweight, and fast – full blown anamorphic Look. Due to their unique construction, the MiniHawks solve problems associated with anamorphic lenses while preserving classic anamorphic characteristics. They offer super-close focus – almost like macro lenses – with no breathing while focusing. MiniHawks are geometrically well-corrected, yet still preserve classic anamorphic characteristics such as elliptical bokeh and shallow depth of field, resulting in an organic cinematic feel.

Technical data MiniHawk - Hybrid Anamorphics

Lens Focal Length Stop CFD MOD Angle of View horizontal Weight Front Diameter Overall Length Min. Filter Size Image Circle Illumination Circle
MiniHawk 29 29 mm/T1.7 0.25 m10“ 0.06 m2 ½“ 84.8° 2.4 kg5.3 lbs 128 mm 158 mm 4x5.65“ 32.2 mm 32.5 mm
MiniHawk 35 35 mm/T1.7 0.25 m10“ 0.06 m2“ 75.8° 2.1 kg4.6 lbs 110 mm 149 mm 4x5.65“ 30 mm 31 mm
MiniHawk 40 40 mm/T1.7 0.25 m10“ 0.06 m2 ½“ 67.7° 1.9 kg4.2 lbs 110 mm 143 mm 4x5.65“ 32.2 mm 32.5 mm
MiniHawk 50 50 mm/T1.7 0.25 m10“ 0.08 m3“ 58.8° 1.8 kg4 lbs 110 mm 128 mm 4x5.65“ 33.5 mm 34 mm
MiniHawk 65 65 mm/T1.7 0.25 m10“ 0.08 m3“ 48.9° 1.9 kg4.2 lbs 110 mm 127 mm 4x5.65“ 34 mm 35 mm
MiniHawk 80 80 mm/T1.7 0.36 m1‘2“ 0.21 m8“ 37.9° 1.6 kg3.5 lbs 110 mm 128 mm 4x5.65“ 34 mm 34.5 mm
MiniHawk 100 100 mm/T1.7 0.3 m1‘ 0.16 m7“ 30.2° 1.5 kg3.3 lbs 110 mm 127 mm 4x5.65“ 36 mm 37 mm
MiniHawk 135 135 mm/T1.7 0.39 m1‘3“ 0.24 m9“ 23.7° 1.7 kg3.7 lbs 110 mm 121 mm 4x5.65“ 38 mm 40 mm
MiniHawk 180 180 mm/T1.7 0.6 m2‘ 0.44 m1‘5“ 18.2° 2.1 kg4.6 lbs 128 mm 130 mm 4x5.65“ 36 mm 44 mm
